Spezifikationen Access-EX

Rahmen E-ACTIVE GEOMETRY SUV, ALLOY 6061 HYDROFORMED D.B. TUBES, Hardtail, DROPOUT 148x12mm BOOST, 29"
Gabel SUNTOUR RAIDON 34 AIR 29" LOR, 15x110mm AXLE, TAPERED, 100mm TRAVEL, REBOUND, LOCKOUT
Motor YAMAHA PW-X 2 45 SERIES, 500 WATT
Batterien SIMPLO, 36V, 630Wh
Display YAMAHA Display C
Unterstützungsstufen ECO+, ECO, STANDARD, HIGH, EXTRA POWER, AUTOMATIC
E-Bike Speed 45 km/h
Schaltwerk SHIMANO XT RD-M8130 SGS SHADOW PLUS DESIGN, 11-SPEED
Schalthebel SHIMANO XT SL-M8130, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Kurbelgarnitur FSA CK-320/ISIS, 42 TEETH
Pedal VP 831, INLEAD GRIP TREAD
Kassette SHIMANO CS-LG600, 11-50 THEETH, 11-SPEED
Kette SHIMANO CN-LG500 11-SPEED
Bremsen SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:180mm ROTORS
Bremshebel SHIMANO BL-M4100, ISPEC EV
Felgen DT SWISS U 623, 32 HOLES, INNER WIDTH 25mm, 29"
Nabe vorne SHIMANO HB-TC500-15-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Nabe hinten SHIMANO FH-TC500-HM-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Vorderreifen ONZA ALLEGRA, 29x2.25"
Hinterreifen ONZA ALLEGRA, 29x2.25"
Vorbau FSA CABLE INTEGRATION STEM, NS ICR, 31.8mm CLAMP
Lenker BIXS HB-RB12W RIZER BAR, 760mm, 9°ANGLE, 15mm RISE, 31.8mm
Steuersatz FSA NO.55R 1.5" / ICR / STD
Sattelstütze KIND SHOCK RAGEi, M & L: 125mm, XL: 150mm TRAVEL, SOUTHPAW-ALLOY REMOTE LEVER, 31.6mm
Sattel ERGON SFC30 GEL
Scheinwerfer SUPERNOVA M99 MINI PURE-45, 500 LUMEN, 230 LUX
Rücklicht SUPERNOVA M99 TAILLIGHT 45
Gepäckträger RACKTIME BIXS CUSTOM WITH INTEGRATED SUPERNOVA REAR LIGHT
Schutzbleche WINGEE, BiXS CUSTOM,  62mm, 29", ALLOY
Gewicht 27.6 KG

Geometrie

Grösse A B C D E F G H I J K L
M 430 610 135 480 73° 68° 1181 45 655 410 310 170
L 480 621 140 480 73° 68° 1192 45 659 419 310 170
XL 530 634 150 480 73° 68° 1206 45 669 429 310 170

A Rahmengrösse
B Oberrohr horizontal mm
C Steuerrohr mm
D Kettenstreben mm
E Sitzwinkel Grad
F Radstand mm
G Radstand mm
H Vorbau mm
I Stack mm
J Reach mm
K Tretlagerhöhe mm
L Kurbellänge mm
