Mariposa-E12 (Sale)

Out of the city, up the mountain or to the lakeside, maybe even off-road. The Mariposa-E is your versatile companion and offers enough usual to leave the beaten track thanks to its 120 mm suspension travel. The powerful Shimano motor is by your side, known for its natural riding feeling. With the agile 27.5-inch wheels and the cleverly angled top tube, the bike scores with a low standover height - perfect for smaller riders.

CHF 3,790.00 ~~CHF 4,390.00~~

Unit price: per

Deep Purple

Which size fits me?

Frame sizes
149 – 163 cm: S
159 – 178 cm cm: M
174 - 188 cm: L

Where to test and buy?

Mariposa-E

Strong, self-confident and reduced to the essentials.

Learn more about the Mariposa-E +

Specifications Mariposa-E12

Frame	E-WOMEN GEOMETRY, ALLOY 6061 HYDROFORMED D.B. TUBES, HARDTAIL, DROPOUT 148x12mm BOOST, 27.5"
Fork	ROCK SHOX 35 SILVER TK SOLO AIR 27.5", 15x110mm AXLE, TAPERED, 120mm TRAVEL, REBOUND, COMP. TO LOCK
Motor	SHIMANO STEPS EP8, 250 WATT
Batteries	DARFON, 36V, 630Wh
Display	SHIMANO SC-E5003
Assistance levels	ECO, TRAIL, BOOST
E-bike speed	25 km/h
Rear derailleur	SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift lever	SHIMANO DEORE SL-M6100, WITH OPTICAL GEAR DISPLAY
Crankset	SHIMANO STEPS FC-EM600, 36 TEETH
Pedal	VPE-857
Cassette	SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Chain	SHIMANO CN-M6100 12-SPEED
Brakes	SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake lever	SHIMANO BL-MT201
Front hub	SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear hub	SHIMANO FH-MT410-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Front tire	SCHWALBE SMART SAM PERFORMANCE, ADDIX, 27.5x2.6"
Rear tire	SCHWALBE SMART SAM PERFORMANCE, ADDIX, 27.5x2.6"
Stem	BIXS 0°ANGLE, 35mm CLAMP
Handlebar	BIXS RIZER BAR, 760mm, 9° BACKSWEEP, 15mm RISE, 35mm
Headset	FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Seat post	KIND SHOCK RAGEi, S: 100mm, M & L: 125mm, SOUTHPAW REMOTE LEVER, 31.6mm
Saddle	BIXS VL-3534
Weight	23 KG

Geometry

Size	A	B	C	D	E	F	G	H	I	J	K	L
S	380	590	135	455	74°	67°	1151	35	625	411	315	165
M	430	595	140	455	74°	67°	1162	50	630	415	315	165
L	480	600	145	455	74°	67°	1170	50	336	420	315	165

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
