Spezifikationen Peak 340

Rahmen TRAIL GEOMETRY, FULL CARBON FRAME, 140mm TRAVEL, DROPOUT 148x12mm BOOST, 29"
Gabel ROCK SHOX REVELATION RC, 15x110mm AXLE, TAPERED, 150mm TRAVEL, REBOUND, COMPRESSION TO LOCK
Dämpfer ROCK SHOX DELUXE SELECT+ RT, DEBON AIR, 2 POS LEVER, 230x57.5, HARDWARE: 30/20mmx8mm
Schaltwerk SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Schalthebel SHIMANO DEORE SL-M6100, CLAMP  TYPE
Kurbelgarnitur SHIMANO FC-MT512, 2-PIECE CRANKSET, S: 30 THEETH, OTHERS 32 TEETH
Innenlager SHIMANO SM-BB52
Kassette SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Kette SHIMANO CN-M6100 12-SPEED
Bremsen SHIMANO BR-MT500, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Bremshebel SHIMANO BL-MT501
Nabe vorne SUNRINGLE WHEELSET DUROC 30 COMP, 32 HOLES, 15x110mm THRU AXLE
Nabe hinten SUNRINGLE WHEELSET DUROC 30 COMP, 32 HOLES, 12x148mm BOOST, THRU AXLE
Vorderreifen ONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29x2.4"
Hinterreifen ONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29x2.4"
Vorbau BIXS 0°ANGLE, 35mm CLAMP
Lenker BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm
Steuersatz ACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5" BLOCK LOCK
Sattelstütze KIND SHOCK RAGEi, S: 100mm, M: 125mm, L: 150mm, XL: 170mm TRAVEL, SHIMANO REMOTE, 31.6mm
Sattel BiXS VL-1831
Gewicht 14.3 KG

Geometrie

Grösse A B C D E F G H I J K L
S 370 566 90 440 77.4 65.4 1179 40 612 430 336 165
M 400 598 100 440 77.4 65.4 1213 40 620 459 336 170
L 430 632 115 440 77.4 65.4 1250 40 634 489 336 170
XL 490 666 135 450 77.4 65.4 1288 50 652 520 336 170

A Rahmengrösse
B Oberrohr horizontal mm
C Steuerrohr mm
D Kettenstreben mm
E Sitzwinkel Grad
F Steuerrohrwinkel Grad
G Radstand mm
H Vorbau mm
I Stack mm
J Reach mm
K Tretlagerhöhe mm
L Kurbellänge mm
