Spezifikationen Storm EQ
| Rahmen | STORM PREMIUM ALLOY HARDTAIL, 5X135MM |
| Gabel | SUNTOUR SF22-NVX30 COIL, 100MM TRAVEL, 5X100MM |
| Schaltwerk | SHIMANO CUES RD-U6000, 10-SPEED |
| Schalthebel | SHIMANO CUES SL-U6000-10R |
| Kurbelgarnitur | SHIMANO CUES FC-U6000-1, CL52, 32T |
| Kassette | SHIMANO CUES CS-LG400-10, 11-48T |
| Kette | SHIMANO CUES CN-LG500 |
| Bremsen | SHIMANO BL-MT201, BR-MT200 2-PISTON |
| Bremsscheiben | SHIMANO SM-RT30, CENTER LOCK, XS: 180/160MM, S-L: 180/180MM |
|
Felgen |
ALEXRIMS MD19, 19MM INNER WIDTH |
|
Nabe vorne |
SHIMANO DH-3D37-QR DYNAMO HUB, 32 HOLES |
|
Nabe hinten |
SHIMANO FH-QC400-HM, 32 HOLES |
| Vorderreifen | SCHWALBE BIG BEN K-GUARD, 27.5X1.95" |
| Hinterreifen | SCHWALBE BIG BEN K-GUARD, 27.5X1.95" |
| Vorbau | BIXS STEM, 0°, 31.8MM CLAMP |
| Lenker | BIXS RIZER BAR, 25MM RISE, 740MM |
| Sattelstütze | BIXS SEATPOST, Ø31.6MM, XS: 300MM, S & M: 3 50MM, L: 400MM |
| Sattel | BIXS VL-3533 |
| Scheinwerfer | TRELOCK LS-383 VEO, 50 LUX, STANDLIGHT AUTOMATIC |
| Rücklicht | TRELOCK LS-613 DUO FLAT, STANDLIGHT AUTOMATIC |
| Gepäckträger | RACKTIME ECO, SNAP-IT SYSTEM |
| Schutzbleche | BIXS CC-049 ALLOY, 61MM WIDE |
| Gewicht | 16.8 KG |
Geometrie
| SIZE | S | M | L | XL | |
| A | Reach | 374 | 394 | 413 | 430 |
| B | Stack | 591 | 591 | 596 | 605 |
| C | Top Tube | 550 | 570 | 590 | 610 |
| D | Seat Tube | 350 | 380 | 430 | 480 |
| E | Head Tube | 105 | 105 | 110 | 120 |
| F | Fork Length | 507 | 507 | 507 | 507 |
| G | Fork Offset | 42 | 42 | 42 | 42 |
| H | Chainstay | 440 | 440 | 440 | 440 |
| I | Seat Angle | 73.3 | 73.3 | 73.3 | 73.3 |
| J | Head Tube Angle | 68 | 68 | 68 | 68 |
| K | BB Drop | 37 | 37 | 37 | 37 |
| L | BB Height | 307 | 307 | 307 | 307 |
| M | Wheelbase | 1087 | 1102 | 1123 | 1144 |
| Stem Length | 35 | 35 | 45 | 55 | |
| Crank Length | 170 | 170 | 175 | 175 |
| Körpergrösse | 149 - 163 cm | 159 - 178 cm | 174 - 188 cm | 185 - 200 cm |
| Rahmengrösse | S | M | L | XL |
