Specifications Core 300

Frame SPORT GEOMETRY ALLOY 6061 HYDROF. T.B., DROPOUT 148x12mm BOOST, HARDTAIL 29"
Fork ROCK JUDY SILVER TK 29", SOLO AIR SPRING, TAPERED, 15x110mm AXLE, 100mm TRAVEL, REBOUND, LOCKOUT
Rear derailleur SHIMANO SLX RD-M7100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift lever SHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Crankset SHIMANO FC-MT511, 2-PIECE CRANKSET, 32 TEETH
Pedal WELLGO C-015
Bottom bracket SHIMANO SM-BB52
Cassette SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Chain SHIMANO CN-M6100 12-SPEED
Brakes SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake lever SHIMANO BL-M4100, ISPEC EV
Front hub SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear hub SHIMANO FH-MT410-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Front tire SCHWALBE SMART SAM K-GUARD, 29x2.35"
Rear tire SCHWALBE SMART SAM K-GUARD, 29x2.35"
Stem BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Handlebar BIXS HB-RB12L, 740mm, 9°ANGLE, 25mm RISE, 31.8mm
Headset FSA NO.57B, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.2mm TOP COVER
Seat post BIXS SP-719, S & M: 350mm, OTHERS: 400mm, 31.6mm
Saddle BIXS VL-3533
Weight 13.6 KG

Geometry

Size A B C D E F G H I J K L
S 380 570 105 455 73.5° 68 1114 35 619 387 308 170
M 430 590 105 455 73.5° 68 1134 45 619 407 308 175
L 480 610 110 455 73.5° 68 1154 55 624 425 308 175
XL 530 630 120 455 73.5° 68 1175 65 633 443 308 175

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
