Core 500 (Sale)

The CORE series has its roots in the origins of mountain biking. It started all with hardtails and hardtails are still as popular as ever. Whether for uncompromising racing, an after-work ride on the home trails or an excursion with the family, these bikes are lots of fun. BIXS' long-standing commitment to racing has left its mark on the DNA of the CORE series. The timeless 29-inch models are available in various configurations to suit every budget.

CHF 849.00 ~~CHF 999.00~~

Unit price: per

Turquoise - Black

Which size fits me?

Frame sizes
149 – 163 cm: S
159 – 178 cm cm: M
174 - 188 cm: L
185 - 200 cm: XL

Where to test and buy?

Core

Go hard.

Learn more about the Core +

Specifications Core 500

Frame	SPORT GEOMETRY ALLOY 6061 HYDROF. T.B. HARDTAIL 29"
Fork	SUNTOUR XCM DS HLO 29", COIL SPRING, TAPERED, 100mm TRAVEL, LOCKOUT
Rear derailleur	SHIMANO DEORE RD-M5120 SGS SHADOW PLUS DESIGN, 10-SPEED
Shift lever	SHIMANO DEORE SL-M4100, WITH OPTICAL GEAR DISPLAY
Crankset	SHIMANO FC-M5100-1, 2-PIECE CRANKSET, 30 TEETH
Pedal	VP 990S
Bottom bracket	SHIMANO SM-BB52
Cassette	SHIMANO CS-M4100, 11-46 THEETH, 10-SPEED
Chain	SHIMANO CN-HG54
Brakes	SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake lever	SHIMANO BL-MT201
Front hub	SHIMANO HB-RM35, 32 HOLES, QR
Rear hub	SHIMANO FH-RM35, 32 HOLES, QR
Front tire	SCHWALBE SMART SAM K-GUARD, 29x2.35"
Rear tire	SCHWALBE SMART SAM K-GUARD, 29x2.35"
Stem	BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Handlebar	BIXS HB-RB12L, 740mm, 9°ANGLE, 25mm RISE, 31.8mm
Headset	FSA NO.57B, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.2mm TOP COVER
Seat post	BIXS SP-3D2, S & M: 350mm, OTHERS: 400mm, 31.6mm
Saddle	BIXS VL-3533
Weight	14.2 KG

Geometry

Size	A	B	C	D	E	F	G	H	I	J	K	L
S	380	570	105	455	73.5°	68	1114	35	619	387	308	170
M	430	590	105	455	73.5°	68	1134	45	619	407	308	175
L	480	610	110	455	73.5°	68	1154	55	624	425	308	175
XL	530	630	120	455	73.5°	68	1175	65	633	443	308	175

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
