| Frame |
E-TRAIL GEOMETRY, ALLOY 6061, 150mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29" |
| Fork |
ROCK SHOX YARI RC 29"/27.5"+, BOOST 15x110mm, TAPERED, 160mm TRAVEL, REBOUND, COMPRESSION TO LOCK |
| Motor |
SHIMANO STEPS EP8, 250 WATT |
| Batteries |
SIMPLO, 36V, 630Wh |
| Display |
SHIMANO SC-EM800 |
| Assistance levels |
ECO, TRAIL, BOOST |
| E-bike speed |
25 km/h |
| Shock |
FOX FLOAT DPS PERFORMANCE, LV, EVOL, 3 POS, 205x65, TRUNNION MOUNT, HARDWARE: 21.8mmx8mm |
| Rear derailleur |
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED |
| Shift lever |
SHIMANO DEORE SL-M6100, CLAMP TYPE |
| Crankset |
SHIMANO FC-EM600, 34 TEETH |
| Cassette |
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
| Chain |
SHIMANO CN-M6100 12-SPEED |
| Brakes |
SHIMANO BR-MT520, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS |
| Brake lever |
SHIMANO BL-MT501 |
| Rims |
SUNRINGLE WHEELSET DUROC 35 COMP, TLR, 28 HOLES, INNER WIDTH 32mm, 29" |
| Front hub |
SUNRINGLE WHEELSET DUROC 35 COMP, 28 HOLES, 15x110mm THRU AXLE |
| Rear hub |
SUNRINGLE WHEELSET DUROC 35 COMP, 28 HOLES, 12x148mm BOOST, THRU AXLE |
| Front tire |
SCHWALBE MAGIC MARY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4" |
| Rear tire |
SCHWALBE BIG BETTY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4" |
| Stem |
BIXS 0°ANGLE, 35mm CLAMP |
| Handlebar |
BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm |
| Headset |
FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER |
| Seat post |
KIND SHOCK RAGEi, M & L: 125mm, XL: 150mm TRAVEL, SOUTHPAW-ALLOY REMOTE LEVER, 31.6mm |
| Saddle |
BIXS E-MTB |
| Weight |
25.1 KG |
