| Frame |
TRAIL GEOMETRY, CARBON, ALLOY ROCKER. 120mm TRAVEL, 29" |
| Fork |
FOX 34 FLOAT PERFORMANCE 29", 15x110mm AXLE, TAPERED, GRIP, TRAVEL: 130mm, 3-POSITION LEVER |
| Shock |
FOX FLOAT DPS PERFORMANCE ELITE, LV, EVOL, 2 POS REMOTE, TRUNION 165x45, 25MM X 8MM HARDWARE |
| Rear derailleur |
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
| Shift lever |
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
| Crankset |
SHIMANO XT FC-M8100-1, HOLLOWTECH II, 32 TEETH |
| Bottom bracket |
SHIMANO MT800 |
| Cassette |
SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED |
| Chain |
SHIMANO CN-M8100 12-Speed |
| Brakes |
SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS, ICE TECH |
| Brake lever |
SHIMANO XT BL-M8100, ISPEC EV |
| Front hub |
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 15mm THRU AXLE |
| Rear hub |
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 12x148mm BOOST, THRU AXLE |
| Front tire |
ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
| Rear tire |
ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
| Stem |
RACE FACE TURBINE R, 0°ANGLE, 35mm CLAMP |
| Handlebar |
RACE FACE TURBINE 35, 760mm, 20mm RISE, 8° BACKSWEEP, 35mm |
| Headset |
STSF17 INTEGRATED WITH CABLE INTEGRAGTION AND CABLE ENTRY DUSTCAP 1.5" UPPER AND LOWER BEARING |
| Seat post |
KIND SHOCK LEV SI, S: 100mm, M & L: 125mm TRAVEL, SHIMANO REMOTE LEVER, 31.6mm |
| Saddle |
ERGON SM10 SPORT GEL WOMEN |
| Weight |
12.6 KG |
