| Rahmen |
E-ACTIVE GEOMETRY, ALLOY 6061, 130mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29" |
| Gabel |
FOX 34 FLOAT AWL 29" E-SUV, 15x110mm AXLE, TAPERED, TRAVEL: 120mm, SWEEP ADJUST LEVER |
| Motor |
YAMAHA PW-X 2 45 SERIES, 500 WATT |
| Batterien |
SIMPLO, 36V, 630Wh |
| Display |
YAMAHA Display C |
| Unterstützungsstufen |
ECO+, ECO, STANDARD, HIGH, EXTRA POWER, AUTOMATIC |
| E-Bike Speed |
45 km/h |
| Dämpfer |
FOX FLOAT DPS PERFORMANCE, LV, EVOL, 3 POS LEVER, 205x60, TRUNNION MOUNT, HARDWARE: 21.8mmx8mm |
| Schaltwerk |
SHIMANO XT RD-M8130 SGS SHADOW PLUS DESIGN, 11-SPEED |
| Schalthebel |
SHIMANO XT SL-M8130, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
| Kurbelgarnitur |
FSA CK-320/ISIS, 42 TEETH |
| Kassette |
SHIMANO CS-LG400, 11-50 THEETH, 11-SPEED |
| Kette |
SHIMANO CN-LG500 11-SPEED |
| Bremsen |
SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:180mm ROTORS |
| Bremshebel |
SHIMANO BL-M4100, ISPEC EV |
| Felgen |
DT SWISS WHEELSET SUV HU-1900 TLR, 28 HOLES, INNER WIDTH 25mm, 29" |
| Nabe vorne |
DT SWISS WHEELSET SUV HU-1900, 28 HOLES, 15x110mm THRU AXLE |
| Nabe hinten |
DT SWISS WHEELSET SUV HU-1900, 28 HOLES, 12x148mm BOOST, THRU AXLE |
| Vorderreifen |
ONZA ALLEGRA, 29x2.25" |
| Hinterreifen |
ONZA ALLEGRA, 29x2.25" |
| Vorbau |
FSA CABLE INTEGRATION STEM, NS ICR, 31.8mm CLAMP |
| Lenker |
BIXS HB-RB12W RIZER BAR, 760mm, 9°ANGLE, 15mm RISE, 31.8mm |
| Steuersatz |
FSA NO.55R 1.5" / ICR / STD |
| Sattelstütze |
KIND SHOCK RAGEi, M & L: 125mm, XL: 150mm TRAVEL, KSGL-ALLOY REMOTE LEVER, 31.6mm |
| Sattel |
ERGON SFC30 GEL |
| Scheinwerfer |
SUPERNOVA M99 PRO 2, 12V. DC, DAYLIGHT WITH SUPER STRONG HIGH BEAM |
| Rücklicht |
SUPERNOVA Q-UL1EK, SPEED PEDELEC TAILLIGHT, 12V. |
| Gepäckträger |
RACKTIME BOOST IT |
| Schutzbleche |
WINGEE, BiXS CUSTOM, 62mm, 29", ALLOY |
| Gewicht |
28.5 KG |
