Das CORE ist deine Eintrittskarte in den Mountainbike-Sport. Erlebe den Fahrspass auf flowigen Trails und ausgiebigen Touren.

CHF 899.00
Grass Green
Welche Grösse passt mir?

Rahmengrössen
149 – 163 cm: S
159 – 178 cm cm: M
174 - 188 cm: L
185 - 200 cm: XL

Wo testen und kaufen?

BIXS Händlerverzeichnis →

Steuern inbegriffen. Versandkosten werden an der Kasse berechnet.
Core 500 Grass Green / Dark Blue - Red
Core 500 Grass Green / Dark Blue - Red
Core 500 Grass Green / Dark Blue - Red
Core 500 Grass Green / Dark Blue - Red
Core 500 Grass Green / Dark Blue - Red
Core 500 Grass Green / Dark Blue - Red

Spezifikationen Core 500

Rahmen SPORT GEOMETRY ALLOY 6061 HYDROF. T.B. Hardtail 29"
Gabel SUNTOUR XCM DS HLO 29", COIL SPRING, TAPERED, 100mm TRAVEL, LOCKOUT
Schaltwerk SHIMANO DEORE RD-M5120 SGS SHADOW PLUS DESIGN, 10-SPEED
Schalthebel SHIMANO DEORE SL-M4100, WITH OPTICAL GEAR DISPLAY
Kurbelgarnitur SHIMANO FC-M5100-1, 2-PIECE CRANKSET, 30 TEETH
Pedal VP 990S
Innenlager SHIMANO BB-MT501
Kassette SHIMANO CS-M4100, 11-46 THEETH, 10-SPEED
Kette SHIMANO CN-HG54 10-SPEED
Bremsen SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Bremshebel SHIMANO BL-MT201
Felgen ALEXRIMS MD-27, 32 HOLES, INNER WIDTH 27mm, 29"
Nabe vorne SHIMANO HB-RM35, 32 HOLES, QR
Nabe hinten SHIMANO FH-RM35, 32 HOLES, QR
Vorderreifen SCHWALBE SMART SAM K-GUARD, 29x2.35"
Hinterreifen SCHWALBE SMART SAM K-GUARD, 29x2.35"
Vorbau BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Lenker BIXS HB-RB12L, 740mm, 9°ANGLE, 25mm RISE, 31.8mm
Steuersatz FSA NO.57B, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.2mm TOP COVER
Sattelstütze BIXS SP-3D2, S & M: 350mm, OTHERS: 400mm, 31.6mm
Sattel BIXS VL-3533
Gewicht 14.2 KG

Geometrie

SIZE S M L  XL
A Reach 387 407 425 443
B Stack 619 619 624 633
C Top Tube 570 590 610 630
D Seat Tube 380 430 480 530
E Head Tube 105 105 110 120
F Fork Length 510 510 510 510
G Fork Offset 51 51 51 51
H Chainstay 455 455 455 455
I Seat Angle 73.5 73.5 73.5 73.5
J Head Tube Angle 68 68 68 68
K BB Drop 68 68 68 68
L BB Height 308 308 308 308
M Wheelbase 1114 1134 1154 1175
  Stem Length 35 45 55 65
  Crank Length 170 175 175 175



Körpergrösse 149 - 163 cm 159 - 178 cm 174 - 188 cm 185 - 200 cm
Rahmengrösse S M L XL
