Stomp 1

So clean and yet so clever. We call it simplexity. A sophisticated geometry ensures more flow. Bolted bottom bracket cups (BSA) and adjustable dropouts are the new carefree package and keep your head clear for the next session. But the absolute highlight is the well-shaped down tube of the newly designed steel frame.

CHF 1,799.00

Unit price: per

Wavy Orange

Which size fits me?

Frame size:
Onesize (26", 145cm+)

Where to test and buy?

Tax included. Shipping calculated at checkout.

Stomp

Jump, flow, stomp, repeat.

Learn more about the Stomp +

Specifications Stomp 1

Frame	PUMPTRACK GEOMETRY, SINGLE SPEED STEELFRAME, 26"
Fork	MARZOCCHI DJ 26", 20x110mm AXLE, TAPERED, GRIP, 100mm TRAVEL, 37mm RAKE
Crankset	RACE FACE AEFFECT 30 THEETH
Pedal	VP 538
Bottom bracket	RACE FACE BB BSA 68/73mm, 24mm
Cassette	NOVATEC SINGLE SPROCKET, 13 THEETH
Chain	KMC Z1 SINGLE SPEED
Brakes	R: SHIMANO BR-MT410, HYDRAULIC DISC BRAKE & F: TEKTRO MD-M300 MECHANICAL DISC BRAKE , 160mm ROTORS
Brake lever	RIGHT: SHIMANO BL-M4100, LEFT: TEKTRO ML520 RS
Rims	ALEXRIMS SUPRA BH, 32 HOLES, INNER WIDTH 25mm, 26"
Front hub	NOVATEC DH61SB, 32 HOLES, 20x110mm BOOST THRU AXLE
Rear hub	NOVATEC, 32 HOLES, 10x135mm AXLE WITH FLANGE NUTS
Front tire	SCHWALBE BILLY BONKERS PERFORMANCE, 26x2.10"
Rear tire	SCHWALBE BILLY BONKERS PERFORMANCE, 26x2.10"
Stem	RACE FACE CHESTER, 0°ANGLE, 31.8mm CLAMP
Handlebar	SPANK SPOON RIZER BAR, 785mm, 10°ANGLE, 60mm RISE, 31.8mm
Headset	FSA NO.42/47 ACB, 1-1/8" UPPER AND 1.5" LOWER BEARING
Seat post	BIXS VL-7122, 200mm, 27.2mm
Saddle	BIXS VL-7122
Frame size	26"
Weight	12.4 KG

Geometry

Size	A	B	C	D	E	F	G	H	I	J	K	L
26"	310	601	110	390	71	69	1045	50	557	410	-	165

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
