Specifications Access-E20

Frame E-TOURING SUV, ALLOY 6061, 29" Boost
Fork SUNTOUR XCR34 Boost AIR 29", 15mm QR, TAPERED, 100mm TRAVEL
Motor YAMAHA PW-X 2 SERIES, 250 WATT
Batteries SIMPLO, 36V, 630Wh
Display YAMAHA Display A
Assistance levels ECO+, ECO, STANDARD, HIGH, EXTRA POWER, AUTOMATIC
E-bike speed 25 km/h
Rear derailleur SHIMANO DEORE RD-M5100 SGS SHADOW PLUS DESIGN, 11-SPEED
Shift lever SHIMANO DEORE SL-M5100
Crankset FSA CK-320/ISIS, 34 TEETH
Pedal VP 831, INLEAD GRIP TREAD
Cassette SHIMANO CS-M5100, 11-51 THEETH, 11-SPEED
Chain SHIMANO CN-HG901-11
Brakes SHIMANO BR-MT400, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:203mm, R:180mm ROTORS
Brake lever SHIMANO BL-MT401
Front hub SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear hub SHIMANO FH-MT400-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Front tire SCHWALBE JONNY WATTS PERF. RACE GUARD, 29x2.35"
Rear tire SCHWALBE JONNY WATTS PERF. RACE GUARD, 29x2.35"
Stem BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Handlebar BIXS HB-RB12W RIZER BAR, 780mm, 9°ANGLE, 25mm RISE, 31.8mm
Headset FSA NO.55R 1.5" / 558
Seat post BIXS, S & M: 350mm, OTHERS: 400mm, 31.6mm
Saddle ERGON SFC30
Weight 24.8 KG

Geometry

Size A B C D E F G H I J K L
M 430 610 135 480 73° 68° 1181 45 655 410 310 170
L 480 621 140 480 73° 68° 1192 45 659 419 310 170
XL 530 634 150 480 73° 68° 1206 45 669 429 310 170

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
