Spécifications Core 100

Cadre SPORT GEOMETRY, SUPERLITE CARBON M40, 12x148mm BOOST DROPOUT, Hardtail 29"
Fourche ROCK SHOX SID SL 29", DEBONAIR, TAPERED, 15x110mm AXLE, 100mm TRAVEL, REBOUND, LOCKOUT
Dérailleur arr. SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED
Levier de vitesse SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Pédalier SHIMANO FC-MT511, 2-PIECE CRANKSET, 32 TEETH
Roulement de pédalier SHIMANO SM-BB52
Cassette SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Chaîne SHIMANO CN-M6100 12-SPEED
Freins SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:160mm ROTORS
Levier de freins SHIMANO BL-M4100, ISPEC EV
Moyeu avant SHIMANO HB-TC500-15-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Moyeu arrière SHIMANO FH-TC500-MS-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Pneu avant SCHWALBE RACING RAY EVO SUPER RACE, ADDIX SPEEDGRIP, TL EASY, 29x2.35"
Pneu arrière SCHWALBE RACING RALPH EVO SUPER RACE, ADDIX SPEEDGRIP, TL EASY, 29x2.35"
Potence BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Guidon BIXS HB-RB12W RIZER BAR, 760mm, 9°ANGLE, 25mm RISE, 31.8mm
Jeu de direction FSA NO.42/48 ACB, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.7mm TOP COVER
Tige de selle BIXS SP-719, S & M: 350mm, OTHERS: 400mm, 30.9mm
Selle BIXS VL-3533
Poids 11.5 KG

Géométrie

TailleABCDEFGHIJKL
S4005799543074°68.5°109160608405310170
M4306039543074°68.5°111570608430310175
L47263311043074°68.5°114670622455310175
XL52066212543074°68.5°117680636480310175

A Taille de cadre mm
B Long. tube horizontal mm
C Long. tube de dir. mm
D Long. bases arrières mm
E Angle tube de selle
F Angle tube de direction
G Base mm
H Potence mm
I Stack mm
J Reach mm
K Hauteur de pedalier mm
L Longueur des manivelles mm
