Spécifications Core-E12

Cadre E-SPORT GEOMETRY, ALLOY 6061 HYDROFORMED D.B. TUBES, HARDTAIL, DROPOUT 148x12mm BOOST, 29"
Fourche ROCK SHOX 35 SILVER TK SOLO AIR 29", 15x110mm AXLE, TAPERED, 120mm TRAVEL, REBOUND, COMP. TO LOCK
Moteur SHIMANO STEPS EP8, 250 WATT
Batterie DARFON, 36V, 630Wh
Display SHIMANO SC-E5003
Mode d'assistance ECO, TRAIL, BOOST
Vitesse max. 25 km/h
Dérailleur arr. SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Levier de vitesse SHIMANO DEORE SL-M6100, WITH OPTICAL GEAR DISPLAY
Pédalier SHIMANO FC-EM600, 36 TEETH
Cassette SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Chaîne SHIMANO CN-M6100 12-SPEED
Freins SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Levier de freins SHIMANO BL-MT201
Jantes ALEXRIMS EM-35, 32 HOLES, INNER WIDTH 35mm, 29"
Moyeu avant SHIMANO HB-TC500-15-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Moyeu arrière SHIMANO FH-TC500-MS-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Pneu avant SCHWALBE SMART SAM PERFORMANCE, ADDIX, 29x2.6"
Pneu arrière SCHWALBE SMART SAM PERFORMANCE, ADDIX, 29x2.6"
Potence BIXS 0°ANGLE, 35mm CLAMP
Guidon BIXS RIZER BAR, 760mm, 9° BACKSWEEP, 15mm RISE, 35mm
Jeu de direction FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Tige de selle KIND SHOCK RAGEi, S: 100mm, M & L: 125mm, XL: 150mm TRAVEL, SOUTHPAW REMOTE LEVER, 31.6mm
Selle BIXS VL-3533
Poids 23.2 KG

Géométrie

TailleABCDEFGHIJKL
S38059013547074°67°117535660401315165
M43059514047074°67°118050665405315165
L48060014547074°67°118650670410315165
XL53063015047074°67°121650675437315165

A Taille de cadre mm
B Long. tube horizontal mm
C Long. tube de dir. mm
D Long. bases arrières mm
E Angle tube de selle
F Angle tube de direction
G Base mm
H Potence mm
I Stack mm
J Reach mm
K Hauteur de pedalier mm
L Longueur des manivelles mm
