Spécifications Lane 160

Cadre ENDURO GEOMETRY, FULL CARBON FRAME, 160mm TRAVEL, DROPOUT 148x12mm BOOST, 29"
Fourche FOX 38 FLOAT PERFORMANCE, 15x110mm AXLE, TAPERED, GRIP2, TRAVEL: 170mm, 4-WAY ADJUSTABILITY
Amortisseur FOX FLOAT X2 PERFORMANCE, 2 POSITION LEVER 230x65, HARDWARE: 30/20mmx8mm
Dérailleur SRAM GX EAGLE AXS, 12-SPEED
Levier de vitesse SRAM EC AXS CONTROLLER RIGHT HAND ROCKER, 2 BUTTON, 12-SPEED
Pédalier SRAM GX EAGLE BOOST, DUB, S: 30, OTHERS 32 TEETH
Roulement de pédalier SRAM BB DUB BSA 73 MTB
Cassette SRAM XG-1295 EAGLE, 10-52 TEETH, 12-SPEED BLACK
Chaîne SRAM CN-GX EAGLE 12-SPEED
Freins SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:180mm ROTORS, ICE TECH
Levier de freins SHIMANO XT BL-M8100
Moyeu avant DT SWISS WHEELSET SPLINE E-1900, 28 HOLES, 15x110mm THRU AXLE
Moyeu arrière DT SWISS WHEELSET SPLINE E-1900, 28 HOLES, 12x148mm BOOST, THRU AXLE
Pneu avant ONZA AQUILA, KEVLAR FOLDABLE, TUBELESS READY, 29x2.4"
Pneu arrière ONZA AQUILA, KEVLAR FOLDABLE, TUBELESS READY, 29x2.4"
Potence RACE FACE AEFFECT R, 0°ANGLE, 35mm CLAMP
Guidon RACE FACE TURBINE R, 780mm/800mm, 20mm RISE, 8° BACKSWEEP, 35mm
Jeu de direction ACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5" BLOCK LOCK
Tige de selle KIND SHOCK LEV INTEGRA, S: 100mm, M: 125mm, L: 150mm, XL: 175mm TRAVEL, SHIMANO REMOTE, 31.6mm
Selle ERGON SM10 ENDURO
Poids 15.6 KG

Géométrie

TailleABCDEFGHIJKL
S3705549044076.564.5118735619420344165
M40058710044076.564.5122035628450344170
L43062211544076.564.5125735642480344170
XL49066013545076.564.5130650660510344170

A Taille de cadre mm
B Long. tube horizontal mm
C Long. tube de dir. mm
D Long. bases arrières mm
E Angle tube de selle
F Angle tube de direction
G Base mm
H Potence mm
I Stack mm
J Reach mm
K Hauteur de pedalier mm
L Longueur des manivelles mm
