| Cadre |
E-TRAIL GEOMETRY, ALLOY 6061, 130mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29" |
| Fourche |
ROCK SHOX 35 SILVER TK SOLO AIR 29", 15x110mm AXLE, TAPERED, 130mm TRAVEL, REBOUND, COMP. TO LOCK |
| Moteur |
SHIMANO STEPS EP8, 250 WATT |
| Batterie |
DARFON, 36V, 500Wh |
| Display |
SHIMANO SC-E5003 |
| Mode d'assistance |
ECO, TRAIL, BOOST |
| Vitesse max. |
25 km/h |
| Amortisseur |
ROCK SHOX DELUX SELECT R, LEVER, DEBON AIR, 205mm, TRUNNION MOUNT, HARDWARE: 30mm x 8mm |
| Dérailleur arr. |
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED |
| Levier de vitesse |
SHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
| Pédalier |
SHIMANO STEPS FC-EM600, 36 TEETH |
| Cassette |
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
| Chaîne |
SHIMANO CN-M6100 12-SPEED |
| Freins |
SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS |
| Levier de freins |
SHIMANO BL-M4100, ISPEC EV |
| Moyeu avant |
SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE |
| Moyeu arrière |
SHIMANO FH-MT410-B, 32 HOLES, 12x148mm BOOST THRU AXLE |
| Pneu avant |
SCHWALBE NOBBY NIC PERFORMANCE, ADDIX SPEEDGRIP, 29x2.6" |
| Pneu arrière |
SCHWALBE NOBBY NIC PERFORMANCE, ADDIX SPEEDGRIP, 29x2.6" |
| Potence |
BIXS 0°ANGLE, 35mm CLAMP |
| Guidon |
BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm |
| Jeu de direction |
FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER |
| Tige de selle |
KIND SHOCK RAGEi, M: 100mm, L: 125mm, XL: 150m TRAVEL, SHIMANO REMOTE LEVER, 30.9mm |
| Selle |
BIXS VL-3533 |
| Poids |
24.6 KG |
