Spécifications Gran Turismo 2

Cadre GRAN TURISMO CARBON ROAD, 12x142mm, FLAT MOUNT DISC
Fourche FULL CARBON ROAD FORK, 12x100mm
Dérailleur arr. SRAM RIVAL ETAP AXS, 12-SPEED
Dérailleur av. SRAM RIVAL ETAP AXS
Levier de vitesse SRAM RIVAL ETAP AXS
Pédalier SRAM RIVAL, CL45, DUB, 48/35T
Roulement de pédalier SRAM BB DUB PF 86.5mm ROAD
Cassette SRAM RIVAL XG-1250, 10-36T
Chaîne SRAM RIVAL
Freins SRAM RIVAL ETAP AXS
Disques de freins SRAM CENTERLINE, CENTER LOCK, 160/160MM
Wheelset DT SWISS E 1800, 22MM INNER WIDTH, 23MM DEPTH
Pneu avant SCHWALBE ONE PERFORMANCE, RACEGUARD, ADDIX, 700x30C
Pneu arrière SCHWALBE ONE PERFORMANCE, RACEGUARD, ADDIX, 700x30C
Potence BIXS STEM, -7°, 31.8mm CLAMP
Guidon SATORI X-RACE PRO, 8° FLARE, S: 400mm, M & L: 420mm, XL: 440mm
Tige de selle BIXS CARBON SEATPOST, D-SHAPE
Selle BIXS VL-1A47
Poids 8.2 KG

Géométrie

TailleABCDEFGHIJKL
XS43050510041574.570.596390504365170
S4675301204157472.596790530378172.5
M49854514041573.573975100545384172.5
L5185601604157373985100565388175
XL53757518041573731000110584397175

A Taille de cadre mm
B Long. tube horizontal mm
C Long. tube de dir. mm
D Long. bases arrières mm
E Angle tube de selle
F Angle tube de direction
G Base mm
H Potence mm
I Stack mm
J Reach mm
K Hauteur de pedalier mm
L Longueur des manivelles mm
